VL-11 Metering Valves

The series VL-11 metering devices are for single-line, high-pressure lubrication system s. viscosity up to NLGI 2. Output is externally adjustable. An indicator pin permits visu al check of metering device operation. Individual metering devices can be removed eas ily for inspection or replacement.

Technical Information of VL-11 Metering Valves

Technical characteristics

Outlets

1

Metering quantity

0.82 - 8.2 ml(adjustable)

Lubricant

Grease NLGI 0, 1, 2

Operating temperature

-40 ~93 °C

Operating pressure

70 to 240 bar

Material

stainless steel、Carbon steel

Connection main line

1/2 NPT (F)

Connection outlet

1/4 NPT (F)


Technical Drawing of VL-11 Metering Valves



Part number

Connection outlet

VL1100

1/4 NPT (F)



Characteristics of VL-11 Metering Valves


  • May be combined in a circuit of metering devices VL-1、VL-1X、VL-1XL、VL- 11、VL-32

  • Output is externally adjustable

  • Each indicator pin permits visual check of injector operation

  • Individual metering devices can be removed easily for inspection or replacement


Cisolube offers custom grease distributor with wide selections, Contact now.


Applications of VL-11 Metering Valves

  • Construction machinery

  • Mining and mineral processing

  • Steel industry
